RUBBER TRACK CARRIER- KUBOTA KC120HC
Pricing Information
Request QuoteProduct Description
- Not only is the KC120HC compact in size, it also provides all the load capacity and dump force needed to efficiently and reliably get the job done.
- The rugged power delivered by the Kubota diesel engine ensures reliable and efficient operation in a wide range of applications.
- Ideal for moving material in confined spaces and over difficult terrain.
- 3 direction dumping.
- BC’s leading equipment rentals and sales resource
- Industry’s most knowledgeable, experienced and helpful staff.
- 24/7 Emergency Support Services
- Mobile Equipment Operator Training
Got a question? We’re here to help. 604-323-1222
Search Inventory
Support Services
Additional Product Info & Specs
Engine
Engine Deck Model: Kubota Z482
Engine Type Liquid cooled, 4 cycle, diesel, Tier 4
Cylinder Liners Two
Engine Power Gross @ rpm: 13.3 HP (9.9 kW) @ 3600 RPM
Starter Electric
Brakes
Brake System Type Wet multi plate
Operational
Operating Speed Drive train/transmission – Low range (Speed range): 2.3/1.5 mph (3.8/2.5 kmh), for/rev | Drive train/transmission – High range: 4.2/2.8 mph (6.9/4.7 kmh), for/rev
Dimensions
Dimensions Cargo box – Dumping angle: Front: 56º / Side: 61º
Overall Length 104.5 in. (2655 mm)
Overall Width 41.3 in. (1050 mm)
Overall Height 55.1 in. (1400 mm) | Cargo box: 12.6 in. (320 mm)
Ground Clearance 5.7 in. (145 mm)
Track Width 9.1 in. (230 mm)
Length Cargo box: 57.9 in. (1470 mm)
Width Cargo box: 36.2 in. (920 mm)
Capacities
Payload Capacity Cargo box – Maximum: 2646 lbs. (1200 kg)
Cargo Capacity Box: 0.56/0.75 cu.yd., struck/heaped
Weights
Weight 1929 lbs. (875 kg)
Features
Features Cargo box – Dumping direction: Forward, Both Sides | Cargo box – Type of dump system available: Hydraulic
